Cummins 62.5 kVA Three Phase Silent Diesel Generator
680700.0 INR/Set
Product Details:
- Engine Type Other
- Alternator Stamford
- Fuel Consumption 11.65 Liter/Hour (L/hr)
- Engine Model 4BTAA3.3-G11
- Dimension (L*W*H) 2950*1150*1550 Millimeter (mm)
- Fuel Tank Capacity 150 Liter (L)
- Bore *Stroke 95*115
- Click to View more
X
Cummins 62.5 kVA Three Phase Silent Diesel Generator Price And Quantity
- 680700.0 INR/Set
- 1 Set
Cummins 62.5 kVA Three Phase Silent Diesel Generator Product Specifications
- Other
- 2950*1150*1550 Millimeter (mm)
- 4BTAA3.3-G11
- water/liquid cooled
- 11.65 Liter/Hour (L/hr)
- Stamford
- 415 Volt (V)
- 1470 Kilograms (kg)
- Other
- 95*115
- 50 Hertz (HZ)
- Electric Start
- Three Phase
- 1500 RPM
- 2years
- 62.5KVA
- 150 Liter (L)
- 75 db
Cummins 62.5 kVA Three Phase Silent Diesel Generator Trade Information
- Telegraphic Transfer (T/T) Cheque
- 1 Set Per Day
- 1 Week
- Australia North America South America Eastern Europe Western Europe Middle East Central America Asia Africa
- All India
Product Description
| Brand | Cummins |
| Aspiration | Turbocharged |
| Current | 87 A |
| Exhaust Temperature | 490 Degree Celsius |
| Mean Piston Speed | 5.75 m/s |
| Starting System | 12 V DC Electrical |
| Total Coolant Capacity | 13 Ltrs |
| Bore X Stroke | 95 mm x 115 mm |
| Compression Ratio | 19/1 |
| Displacement | 3.3 Ltrs |
| Exhaust Pipe Size | 3 Inches |
| Enclosure | IP23 |
| Stator Winding | Double layer lap |
| Fuel Consumption | 11.65 Ltrs/Hr (At 75% Load),15.13 Ltrs/Hr (At 100% Load) |
| Lube Oil Specification | CI4+ 15W40 |
| Power Rating | 62.5 kVA / 50 kWe |
| No Of Phases | 3 |
| Model | 4BTAA3.3-G11 |
| Required Power For Rated kVA | 81 hp |
| No Of Cylinders | 4 |
| Fuel | High Speed Diesel |
| Performance class Of Generator set | ISO 8528-5 G2 |
| Lube Oil Sump Capacity | 5.5 To 7 Ltrs |
| Total Lubrication System Capacity | 7.9 Ltrs |
| Total Wet Weight | 375 Kg |
| Dimensions | 973 mm(L) x 784 mm(W) x 870mm(H) |
| Combustion Air Intake | 160 cfm At 100% Load |
| Voltage Regulation | +/- 1% |
| Class Of Insulation | Class H |
| Waveform Distortion | No load Less Than 1.5 %,Non distorting balanced linear load Less Than 5 % |
| Maximum Unbalanced Load Across Phases | Less Than Equal To 25% |
| Telephonic Harmonic Factor | Less Than 2% |
| Genset Model | C62.5D5P |
| kVA Prime | 62.5 kVA |
| Alternator Frame | UCI224V |
| Genset Controller | PSO500 |
| MoEF Certified Power | 84 Bhp |
| Cooling | Liquid Cooled (EG Compleat 5050) |
| Rotor | Dynamically Balanced |
| Winding Pitch | 2/3 |
Lowest Operating Cost and Comprehensive Warranty:
- Highly reliable and durable product
- All elements are designed to work together to maximize efficiency even at part loads, offering the advantage of lowest operating costs.
- 500 Hours/ 1 year service interval
- Industry acknowledged best-in-class comprehensive warranty on the entire package including rubber components
