    Cummins 62.5 kVA Three Phase Silent Diesel Generator Cummins 62.5 kVA Three Phase Silent Diesel Generator
    Cummins 62.5 kVA Three Phase Silent Diesel Generator
    Cummins 62.5 kVA Three Phase Silent Diesel Generator

    Cummins 62.5 kVA Three Phase Silent Diesel Generator

    680700.0 INR/Set

    Product Details:

    • Engine Type Other
    • Alternator Stamford
    • Fuel Consumption 11.65 Liter/Hour (L/hr)
    • Engine Model 4BTAA3.3-G11
    • Dimension (L*W*H) 2950*1150*1550 Millimeter (mm)
    • Fuel Tank Capacity 150 Liter (L)
    • Bore *Stroke 95*115
    • Click to View more
    X

    Cummins 62.5 kVA Three Phase Silent Diesel Generator Price And Quantity

    • 680700.0 INR/Set
    • 1 Set

    Cummins 62.5 kVA Three Phase Silent Diesel Generator Product Specifications

    • Other
    • 2950*1150*1550 Millimeter (mm)
    • 4BTAA3.3-G11
    • water/liquid cooled
    • 11.65 Liter/Hour (L/hr)
    • Stamford
    • 415 Volt (V)
    • 1470 Kilograms (kg)
    • Other
    • 95*115
    • 50 Hertz (HZ)
    • Electric Start
    • Three Phase
    • 1500 RPM
    • 2years
    • 62.5KVA
    • 150 Liter (L)
    • 75 db

    Cummins 62.5 kVA Three Phase Silent Diesel Generator Trade Information

    • Telegraphic Transfer (T/T) Cheque
    • 1 Set Per Day
    • 1 Week
    • Australia North America South America Eastern Europe Western Europe Middle East Central America Asia Africa
    • All India

    Product Description

    Brand Cummins
    Aspiration Turbocharged
    Current 87 A
    Exhaust Temperature 490 Degree Celsius
    Mean Piston Speed 5.75 m/s
    Starting System 12 V DC Electrical
    Total Coolant Capacity 13 Ltrs
    Bore X Stroke 95 mm x 115 mm
    Compression Ratio 19/1
    Displacement 3.3 Ltrs
    Exhaust Pipe Size 3 Inches
    Enclosure IP23
    Stator Winding Double layer lap
    Fuel Consumption 11.65 Ltrs/Hr (At 75% Load),15.13 Ltrs/Hr (At 100% Load)
    Lube Oil Specification CI4+ 15W40
    Power Rating 62.5 kVA / 50 kWe
    No Of Phases 3
    Model 4BTAA3.3-G11
    Required Power For Rated kVA 81 hp
    No Of Cylinders 4
    Fuel High Speed Diesel
    Performance class Of Generator set ISO 8528-5 G2
    Lube Oil Sump Capacity 5.5 To 7 Ltrs
    Total Lubrication System Capacity 7.9 Ltrs
    Total Wet Weight 375 Kg
    Dimensions 973 mm(L) x 784 mm(W) x 870mm(H)
    Combustion Air Intake 160 cfm At 100% Load
    Voltage Regulation +/- 1%
    Class Of Insulation Class H
    Waveform Distortion No load Less Than 1.5 %,Non distorting balanced linear load Less Than 5 %
    Maximum Unbalanced Load Across Phases Less Than Equal To 25%
    Telephonic Harmonic Factor Less Than 2%
    Genset Model C62.5D5P
    kVA Prime 62.5 kVA
    Alternator Frame UCI224V
    Genset Controller PSO500
    MoEF Certified Power 84 Bhp
    Cooling Liquid Cooled (EG Compleat 5050)
    Rotor Dynamically Balanced
    Winding Pitch 2/3

    Lowest Operating Cost and Comprehensive Warranty:
    • Highly reliable and durable product
    • All elements are designed to work together to maximize efficiency even at part loads, offering the advantage of lowest operating costs.
    • 500 Hours/ 1 year service interval
    • Industry acknowledged best-in-class comprehensive warranty on the entire package including rubber components
